Kinds of Jib Cranes
Jib cranes are made up of a trolley hoist on a horizontal load-bearing boom. This boom is attached to a pivoting vertical member and up to 20 feet long. Jib cranes could move loads between any areas within the boom's arc of rotation. Light duty units are used in warehouses and factories for loads weighing as much as 5 tons. The BestJibCranes.com website showcases the major jib crane models as being either mast mounted, free-standing or wall-mounted.
Free Standing
The free-standing jib crane units do not need any support from the building structure and are able to stand by themselves. The horizontal boom in this case is attached to a pivoting vertical column which is anchored solidly to the floor of the building. This type of jib crane requires a foundation made of either steel or concrete and could rotate a full 360 degrees.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the bottom and the top. These pivots are attached to the building floor and the overhead steel structure. These jib-cranes offer 360 degrees of rotation with the benefit of not requiring the massive foundation needed for free-standing units.
Wall Mounted
The wall-mounted jib cranes provide a horizontal boom which is attached to the building wall as opposed to the typical vertical column. These machinery are great in places where the full 360 degree rotation is not required and offer up to 200 degrees of rotation.
There are two model varieties, depending on how the boom is supported. One of the types utilizes a tie rod that is connected from above the wall to the boom. The other variety supports the boom from below by using a cantilever brace that is also attached to the wall.
